AC sources, capacitors, and inductors are represented by their AC models.Multisim constructs this matrix using the following approach: A complex matrix, containing both real and imaginary components is created.DC operating Point Analysis is performed to obtain the small-signal models.Multisim performs AC Analysis using the following process: The result of an AC Analysis is displayed in two parts: gain versus frequency and phase versus frequency. Then, the equivalent circuit is analyzed from a start to a stop frequency. In AC Analysis, the DC operating point is first calculated to obtain linear, small-signal models for all nonlinear components. AC Analysis is used to calculate the small-signal response of a circuit.
